Yfe phase sequence indicator yf-80 free shipping
YFE Phase Sequence Indicator YF-80
1) Electronic circuit configuration allows more specific function display.
2) YF-80 can detect the phase sequence(R-S-T) of 3 Phase AC Circuit
3) Phase-rotation indication: by both audio and indicator.
4) Phase open-circuit detection: by indicator.
5) Automated detection for low-battery capacity: YF-80 will pick up automatically the insufficient battery power and display it by the indicator. Insufficient battery power will lead to error in testing.
1. Testing Frequency: 45-65Hz
2. Testing Voltage: 50-500V (overload protection: 750V)
* Operating temp./RH: 0-40 degrees Celsius/80% RH below.
* Storage temp./RH: -10 to 60 degrees Celsius/70% RH below
* Insulation Voltage withstand protection: DC 6KV.
* Dimension & Weight: approximately 206g. (including battery)
* Power supply: 9V NEDA 1604 IEC 6F22 JIS 006P.
* Rated enviromental conditions:
* Ambient temperature 5 to 40 degrees celsius
* Relative humidity 80%.
* Installation categories III.
* Double and Reinforce Insulation.
Battery and Carrying Case Included
