Wavetek model 145 20MHZ pulse/finction generator 30VA
Wavetek Model 145 20MHz Pulse/Finction Generator 30VA
The Wavetek 145 combines the features of a function generator and a pulse generator in a single, compact unit. As a function generator it provides sine, triangle, and square waves over a wide 0.0001 Hz to 20 MHz frequency range. As a pulse generator, the Model 145 produces pulses with independent variable delays and widths.
* 0.0001 Hz to 20 MHz Frequency Range
* 15 Volt Peak-to-Peak Output into 50
* Continuous, Triggered and Gated Operation
* Delayed and Double Pulse Outputs
