New agilent N3900A otdr & jilong kl-300T fusion splicer
* Jilong KL-300T Fusion Splicer
* KL-21B High Precision fiber cleaver
* Internal rechargeable Li battery
* Agilent N3900A Mainframe v1.11
* Agilent N3910AM Singlemode Module
* Installed Option 021: Straight physical contact connector
* EXFO FLS-235B Pocket VFL with Case
* Agilent OTDR Traceviewer III Plus
* Soft Casrrying Case With Strap
Fusion Splicer Introductory Price Of $6,295
Jilong KL-300T Automatic Core Alignment Fusion Splicer & Agilent N3900A Modular Network Tester OTDR With N3900AM Singlemode 1310nm & 1550nm Module
This Fusion Splicer Is Brand New, Includes 1 Year Warranty!!
The Agilent OTDR Includes 90 Day Warranty
This Fusion Splicer Is Comparable To The Fujikura FSM-50S
Includes Attached Heat Shrink Oven, Fiber Cleaver, Custom Hard Case & Full Accessories As Well As Complete OTDR Accessories & Carrying Case!
Working Condition: Perfect/Excellent
Warranty: 1 Year Limited /90 Day Exchange
The KL-300T Core Alignment fiber optic fusion splicer made by Jilong Communication is a solid reliable addition to any Technician s tooling. In side by side specification comparisons the KL comes up first in more categories than the big three, Fujikura, Sumitomo or Fitel. The 300 triumphs in attributes like a 39 second splice/shrink cycle time, the second highest magnification on the market and lighter weight than all other standard fusion splicers.
But the KL-300T stands out even more with features that can t be weighed & measured and put into a chart. Each and every time you interact with this machine you will appreciate features like a lighted fusion area, the largest screen on the market, a high resolution graphical user interface, easy to interpret universal buttons and frustration free menu navigation. Additionally when you see the video from the high resolution cameras you ll know you ve got a machine that will spoil you.
* Core to core alignment by PAS technology
* ( PAS:Profile Alignment System)
* Digital fusion splicer with automatic focus function
* Fiber core can be display clearly
* Single X or Y view and X & Y view simultaneously
* Auto detect cleaved endface fault
* Display fiber cleaved and offset angle
* Display core and clad offset
* 5.6 inch TFT color LCD monitor with clear digital image display
* Software upgrade via USB interface
SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZDS (ITU-T G.655)
8~16mm Coating diameter 250 m 16mm Coating diameter: 250 ~ 1000 m
Cladding diameter 80 ~150 m Coating diameter 100~ 1000 m
0.02dB SM , 0.01dB (MM), 0.04dB (DS), 0.04dB( NZDS)
Typical 9 sec with standard SM fiber
4000 results 20 parameter per result
Fiber display and magnification
300X X or Y view ,150X X and Y view
60mm, 40mm and a series of micro sleeves
Typical 150 cycles (splice/tube heat) with inner Li-battery
5.6 TFT inch color LCD monitor
0 ~ 5000m above sea level, 0 ~ 95%RH and -10 50 C, respectively, Max. wind velocity of 15m/s
AC 100-240V with AC adapter; inner Li-battery(6600mAH)
150mm(L) x150mm (W) x150mm (H)
2.7 Kg excluding battery,3.2 Kg including battery
Auto \Calibrate Normal \Special
Fiber cleaved angle threshold set
Auto detect cleaved endface fault
Fiber partial core Compensation
Arc strength automatic adjustment
Ergonomic design The Modular Network Tester feels like an extension to your arm. It has a hand strap, an ergo grip, and a shoulder strap to work with you and keep your hands free. Attaching a fiber optic connector to a test engine has never been so safe and fast. The pop-up connector can be raised for connection and cleaning purposes and sits securely in the down position, protected by a dust cover while in transit.
* Rugged lightwight and ergonomic design.
* Large, brilliant 10.4" color display, with touch screen functionality and cursor control.
* USB & LAN ports for connectivity to your PC
* Secure and rugged data storage
* One day battery operating time
Internal Memory: 170 MB available memory
3.5 floppy disk drive: for high density, 720/1440 KB floppy disks. MS-DOS format compatible.
One Type III or two Type II PC Card slots
SVGA-LCD: 25.9 cm (10.4 ) color TFT display
Universal Serial Bus (USB 1.1): for connection with USB Video Microscope Camera N3988A
USB 1.1 Peripheral: Transmission for up to 12 Mbit/s
RS232C: 9-pin, maximum baud rate 115200 baud.
Parallel Port: 25-pin, standard parallel port (Centronics)
LAN: RJ-45 jack, (Ethernet 10/100)
Keyboard: PS/2 port (Mini-DIN) for English Standard, PS/2 or AT keyboard
VGA: Analog monitor output with SVGA resolution, 60 Hzb
Headset: Standard microphone and speaker plugc
Operating temperature: 0 C to +50 C
Storage temperature: -20 C to +60 C (without battery)
Humidity: 95% Relative humidity from 0 C to +40 C
Dimensions: 230 mm H, 330 mm W, 61 mm D (9.0 x 13 x 2.4 )
Weight: net 3.3 kg (7.5 lbs), including battery pack.
AC: 100 240 Vrms 10% 50 60 Hz.
Battery operating time: typically 5 hours continuous measurements with standard OTDR test engine at 50% backlight setting.
Charging Time: < 3 hours non-operating
Battery deep discharge protection: provided
The Agilent OTDR Module N3910AM works together with the Agilent Modular Network Tester, and are easy to snap on. The OTDR application is uploaded in seconds due to the dynamic software architecture, and allows plug and play operation. Each OTDR test engine has built-in RISC processing power for fast and accurate trace acquisition and data processing. These test engines work in parallel processing mode with other connected test engines, for example, the 1x12 Switch module. All OTDR modules can be shared between multiple users, without the need for any software changes.
* All Done. All Right. After the measurements have been taken the Pass/Fail Test will automatically check for attenuation and insertion and return loss. The new Bending Test will locate both macro and micro bends.
* Easy Connector access and protection. The pop-up connector solves many common problems. For easy access to the optical fiber connection, the pop-up connector is released to the up position, where a fiber can be attached without any obstacles, or the connector cleaned. This also minimizes the risk of scratches to the connector. In the down position with the dust cover closed, the connector stays protected and clean during transit.
* Attach the right connector. Agilent's universal connector interface allows a large range of standard fiber optic connectors, such as FC/PC, SC, and LC, to be connected to the OTDR port. The connector interfaces are easy to attach, even when working on site, and once removed, the fiber ferrule is easily accessible for cleaning.
