30" deltronics dh 30 optical comparator, MPC5 dro & ed
30" Deltronics DH 30 OPTICAL COMPARATOR, MPC5 DRO & ED
30" Screen Deltronics DH 30 OPTICAL COMPARATOR, MPC5 DRO & EDGE DET., AMS CNC, LENSES
30" DELTRONIC OPTICAL COMPARATOR
SCREEN DIAMETER:......................... 30"
TABLE SIZE:.............................. 9" X 25"
MEASURING CAPACITY (TABLE TRAVEL),LONG.:. 12"
MAX. WEIGHT CAPACITY ON TABLE:........... 500 LBS.
FOCUS TRAVEL:............................ 3"
HELIX ROTATION (TO 5' OF ARC):........... +/- 15 DEGREES
HORIZONTAL PROFILE ILLUMINATION WITH TUNGSTEN HALOGEN
TWIN BEAM FIBER-OPTIC SURFACE ILLUMINATION WITH TUNGSTEN
MANUALLY OPERATED CONDENSER LENS TURRET WITH
POWER DRIVE ON X& Y AXES WITH REMOVABLE PENDANT JOYSTICK
CONTROL FOR PRESELECTED JOG SPEED AND INFINITELY
#MPC-5 DELTRONIC TWO AXIS COMPUTERIZED DIGITAL READOUT
WITH PROGRAMMABLE GEOMETRIC FUNCTIONS AND RS-232 PORT
"INTELITOUCH" REMOTE FUNCTION KEYPAD MOUNTED ON THE
JOYSTICK CONTROL GIVING THE OPERATOR A SUBSET OF
#MPC-5'S FRONT PANEL FUNCTIONS
DIGITALLY DISPLAYED ANGLE PROTRACTOR ON SCREEN
360 DEGREE SWIVEL VISE HOLDING FIXTURE
APPROX. DIMENSIONS (LESS CANOPY) 55" L-R X 90" F-B, X 86" H
