Exfo fva-60A mm fiber variable attenuator fva-60 fva
* EXFO FVA-60A-C32-RS Variable Attenuator
EXFO FVA-60A Multimode 850nm 1300nm Variable Attenuator
- System testing and acceptance
- Power meter calibration and verifi cation
- Field, manufacturing and R&D applications
Three attenuation display modes:
- Absolute (including insertion loss)
- Relative (in reference to 0.00 dB level)
Includes Hard Carrying Case & Full Assessories!
This portable variable attenuator performs just as well in a laboratory environment as it does in the field. Superior specifications make it the variable attenuator of choice for a number of applications. For lab or fieldwork flexibility, choose the FVA-60A.
* Typical 2.5 dB insertion loss
* Automatic attenuation sequence with Program mode
* Standard Universal Interface
Three attenuation display modes
* Absolute (including insertion loss)
* Relative (in reference to 0.00 dB level)
Cycles through a repeatable sequence of up to 60 attenuation steps, pausing for one second or up to 60 hours at a time. The Program mode is particularly suited to accelerated bit-error-rate (BER) testing.
Fourteen available wavelengths
Matches your source wavelength to the nearest 10 nm for unbeatable accuracy.
Scans the complete attenuation range at four different speeds according to the selected step size (0.05, 0.20 or 1.00 dB/step and variable step size).
Operate the FVA-60A remotely from your PC using the standard RS-232 interface and control codes. Program software solutions are adapted to your testing needs.
Three-Way Powering Goes a Long Way
The FVA-60A features three complementary power sources for extended operation: a rechargeable NiCd battery, a 9 V alkaline backup battery and an AC adapter/charger for continuous operation.
High-quality optical components make the FVA-60A Variable Attenuator the standard for performance and flexibility. EXFO s computer-assisted calibration techniques deliver remarkable specifications:
The FVA-60A enables consistent operation in various manual or automated testing situations.
* System testing and acceptance
* Power meter calibration and verification
* Field, manufacturing and R&D applications
