Eico model 666 (or 667) tube tester instruction manual
EICO model 666 Tube Tester Instruction Manual! Several Models Available!
The model 666 Instruction manual includes: General Description, Functions of Controls, Operating Instructions, Circuit Description, Maintenance (including Calibration), Roll Chart Replacement, Special Applications (including testing tubes not on the charts), Parts List, and a Schematic Diagram.
Also included is a Tube Supplement Chart for testing tubes not on the roll chart such as newer tubes, antique tubes, or "obsolete or seldom used" tubes, a Tube Inter-changeability Chart, and a VT to RMA tube number conversion chart. The model 666 Construction Manual pages can be added for an additional $4.00.
This very clear copy was made on a new, high resolution Brother Laser copy machine on premium bright white, 24 pound paper. This nice manual is 8 1/2 x 11 inches. This manual includes comb binding with a heavy clear front cover and a card stock rear cover. This binding protects the manual and it will lay flat when open making it easy to use. This manual looks MUCH better than the picture of the model 666 manual shown.
The Assembly Manual is also available for most models for a small additional cost.
Tube Setup Data Books are available for the following (Please inquire for prices):
The typical Instruction Manual includes: Description, Operating Instructions, a procedure for testing tubes not on the roll chart, Roll Chart replacement, Parts List, Schematic Diagram, and a Tube Chart Supplement. This supplement includes setup info for tubes not on the roll chart such as newer tubes, antique tubes, or "obsolete or seldom used" tubes.
