> Reflex klystron k-166, military grade.
Reflex klystron k-166, military grade.
REFLEX KLYSTRON K-166, Military grade.
As with most Russian military products specs are not easy to locate, some of the data is denoted in the leading slip.
Negative repeller Voltage -50V to -350V
The resistance value in the repeller circuit no more than 100KOhm
Frequency stabilization time 5min max
Cooling: forced air. Air flow velocity should be 3meters/second.
When switching on apply voltages in following order:
2. Apply filament voltage, let the klistron heat up for 1 minute.
3. Apply negative repeller voltage.
4. Apply the resonator voltage.
Repeat steps 1-4 backwards when switching the klystron off.
Frequency goes up when upon turning the tuning bolt counterclockwise.
The klystron is assigned an individual number and is being tested against the specs.
