New T1 autonics preset electronic counter CT6S in box
AUTONICS Counter/Timer CT Series CT6S
Counters & timers are the basic tools widely used in automation process of various industries. Autonics offers the wide range of industrial counters and timers, designed, manufactured and tested to meet the most demanding worldwide standards and ratings. They also offer reliable design, quick replacements, panel space-saving and solutions that offer increased functionality, flexibility and performance.
DIN W72 H36mm, W48 H48mm, W72 H72mm Touch Type Counter/Timer
* Selectable Counter or Timer function
* Multi-functional Counter/Timer(Includes 829,728 functions)
* High speed counting of 10kcps
* Batch counter function for CT6, CT6-2P only
* Selectable Voltage input(PNP) or No voltage
* Able to set ON/OFF time individually in Flicker (FLK) mode
AC Power : Indicator : Approx. 9VA, Single & Dual preset : Approx. 6W
Indicator & Single preset : Approx. 5W, Dual preset : Approx. 10VA
0.001 ~ 99.999 (6 digits) , (0.01 ~ 9.99 (4 digits)
Counter : Reset input : Selectable 1ms or 2ms
Timer : INA, INHIBIT, RESET : Selectable 1ms or 20 ms
Voltage input, No voltage input(PNP, NPN selectable)
[Voltage input] Input impedance : 5.4k , "H" level : 5-30VDC, "L" level : 0-2VDC
[No voltage input] impedance at short-circuit : Max. 1k , Residual voltage at short-circuit : Max. 2VDC, impedance at open-circuit : Min. 100k
10 / 50 / 100 / 200 / 500 / 1000 / 2000 / 5000ms
SPDT (1c), Dual preset type: SPST (1a) for first / Second output
No : 250VAC 3A at resistive load,
NC : 250VAC 2A at resistive load
10 years (When using nonvolatile semiconductor memory)
