79" tbl 20HP spdl tos FA5B-h horizontal mill, vertical
79" Tbl 20HP Spdl Tos FA5B-H HORIZONTAL MILL, Vertical
79" Table 20HP Spindle Tos FA5B-H HORIZONTAL MILL, Vertical Head Attach,#50 Taper,2 Arbor Supports,
TOS HORIZONTAL MILLING MACHINE
MODEL: FA5B-H S/N: 19683 NEW: 1977
TAPER IN SPINDLE ................... #50
TABLE SIZE ......................... 17-3/4" x 78-3/4"
LONGITUDINAL TABLE TRAVEL .......... 55"
SADDLE CROSS TRAVEL ................ 17"
KNEE VERTICAL TRAVEL ............... 18"
MAXIMUM TABLE LOAD ................. 2,650 LBS
SPINDLE SPEEDS (20)................. 18 TO 1400 RPM
LONGITUDINAL & CROSS FEEDS (15) .... .4 - 49 IPM
VERTICAL FEEDS (15) ................ .098 - 12 IPM
MAXIMUM DISTANCE SPINDLE TO TABLE .. 22"
MINIMUM DISTANCE SPINDLE TO TABLE .. 4.5"
APPROXIMATE WEIGHT ................. 12,000 LBS
VERTICAL HEAD ATTACHMENT WITH #50 SPINDLE
POWER FEEDS & RAPID TRAVERSE ALL DIRECTIONS
MACHINE MAINTENANCE & INSTRUCTION MANUAL
CONDITION: **** VERY GOOD ****
