28" x 1HP spdl bridgeport tru-trace 1090 / 360/3D trace
28" X 1HP Spdl Bridgeport TRU-TRACE 1090 / 360/3D TRACE
28" X Axis 1HP Spindle Bridgeport TRU-TRACE 1090 / 360/3D TRACER MILL, 360 3D TRACER, 60" Table, Two
TABLE SIZE ........................... 9" x 60"
MAX WEIGHT OF WORKPIECE ON TABLE ..... 750 LBS
LONGITUDINAL (HYDRAULIC) (X) ... 28"
CROSS (HYDRAULIC) (Y) .......... 12"
VERTICAL, KNEE (MANUAL) (Z) .... 14"
RAM TRAVEL ........................... 12"
TABLE GAUGE LINE ............... 1/2"
MIN/MAX THROAT DISTANCE .............. 5-1/2"/ 17/1/2"
SPINDLE SPEEDS (8) ................... 80, 135, 210, 325,
POWER SPINDLE FEEDS (3) .............. .0015, .063, .006 IPR
SPINDLE TRAVEL ....................... 5"
TAPER IN SPINDLE ..................... R-8
MILLING FEED RATE .................... 1-40 IPM
APPROX WEIGHT ........................ 3500 LBS
* COMPLETELY AUTOMATIC THREE DIMENSIONAL TRACING
* AUTOMATIC 360 DEGREE DUPLICATING
* ABILITY TO BE USED AS A THREE DIMENSIONAL MANUAL TRACER
* TIBON CHROME-PLATED HORIZONTAL WAYS
* BIJUR ONE-SHOT LUBRICATION SYSTEM
* TRUE-TRACE 1090 B360/3D TRACING VALVE, S/N: 4105
5HP 3/60/230-460 VOLT HYDRAULIC PUMP MOTOR & TANK
* (2) 1 HORSE POWER STEP-PULLEY BRIDGEPORT MILLING HEADS
INSPECT UNDER POWER IN OUR NEW JERSEY WARHOUSE
