ADS1062CA 60MHZ sampling rate 1G digital oscilloscope
ADS1062CA 60Mhz Sampling Rate 1G Digital Oscilloscope
ATTEN ADS1000 series digital storage oscilloscopes combine mature and steady hardware configuration, high-powered digital signal processing technology and functionality concepts with a mainstream display interface and the operation panel. In our design we did not attempt to match the specifications and usability of other comparable products currently on the market, but rather to exceed them in every respect, often outperforming same level products internationally.
* Dual channel - channel bandwidth: 60MHz
* The volume exquisite and it is convenient for carrying
* Use Colored TFT LCD, the waveform display is clearer and stable
* The real time sampling rate is 500MSa/s
* Memory depth of ADS1000 is 4K and that of ADS1000M is 2M
* Trigger Modes: Edge, Pulse, Video, Slope, Alternative and Delay trigger modes
* Front and Back USB Host/Device, GPIB
* Waveform recorder function
* Thirty two parameters Auto measure function
* Cursor measure covers Manual mode, Track mode and Auto mode
* Channel waveform and it's FFT waveform display on split screen
* Pop-up Menu display pattern is more convenient for users using it
* Multiple Language User Interface
* Support multilingual online help
* Sampling Rate: Single Channel:1Ga/s;Double Channels:500Msa/s
* Equivalent Sampling Rate: 50GSa/s
* Memory Depth:Single Channel: 2M; Double Channels: 1M/CH
* Input Impedance:1M ohm || 17pF
* Sec/div Range:5ns/div-50s/div
* Display:Color TFT(320*234)5.7 LCD
* 1 instruction CD and User Manual
