6" w 18" l mitsui-seiki msg-205MH surface grinder, roll
6" W 18" L Mitsui-Seiki MSG-205MH SURFACE GRINDER, ROLL
6" Width 18" Length Mitsui-Seiki MSG-205MH SURFACE GRINDER, ROLLER BEARING TABLE, PMC
6" X 18" MITSUI (MADE IN JAPAN)
HIGH-PRECISION HAND FEED SURFACE GRINDER
MODEL: MSG-205MH S/N: 84032506 NEW: 1984
NOMINAL CAPACITY .............................. 6" X 18"
MAX. HEIGHT FROM TABLE SURFACE TO THE
GRINDING WHEEL SPINDLE CENTER .................... 18"
LONGITUDINAL TABLE TRAVEL .......................... 20"
MOVEMENT OF TABLE PER HANDWHEEL REV. ............... 4"
STANDARD GRINDING WHEEL .............. 7" X 1/2" X 1-1/4"
PER ONE REVOLUTION ............................. 0.05"
PER ONE DIVISION ............................... 0.0001"
BY VERNIER ..................................... 0.00001"
FINE FEED KNOB, GRAD ........................... 0.00005"
PER ONE REVOLUTION ............................. 0.1"
PER ONE DIVISION ............................... 0.001"
BY VERNIER ..................................... 0.0001"
APPROX. WEIGHT ................................ 1,750 LBS.
APPROX. DIMENSIONS ...................... 66" X 46" X 71"H
1-1/3 HP, MITSUI DIRECT DRIVE SUPER-PRECSION SPINDLE
6" X 18" "O.S. WALKER" FINE-DIVISION PERMANENT
MACHINE IS WIRED FOR 3/60/220 VOLT OPERATION
