Vynckier vm 7X5X5 clear mini-electrical enclosure+2 i/o
Vynckier VM 7x5x5 Clear Mini-Electrical Enclosure+2 I/O
* 1 - Gordos-Crouzet Digital DR-Input Module
* DIN-Rail Mountable Input Module
* Single Point Input Module
* DC Input for 3.3 to 32 V
* UL Recognized (E46203)/CSA Certified (38595)
* 4kV Optical Isolation
* Input and Output Barrier Strips accept 14-28 AWG wire
* Nominal Voltage: 5 - 28 VDC
* Maximum Voltage: 32VDC/VAC
* Minimum Voltage: 4.0 VDC/VAC
* Maximum Current: 34 mA
* Drop-out Current: 1 mA
* Allowable Current: 1.5 mA
* Voltage for No Output: 2 VDC
* Nominal Logic Supply Voltage: 24 VDC
* Maximum Logic Supply Voltage: 30 VDC
* Minimum Logic Supply Voltage: 20 VDC
* Maximum Logic Supply Current: 28 mA
* Maximum Logic Supply Leakage Current: 10 A
* Maximum Voltage: 30 VDC
* Maximum Current: 50 mA
* Maximum Leakage Current: 10 A
* Maximum Voltage Drop: 0.2 VDC
* 1 - Gordos-Crouzet Digital DR-Output Module
* DIN-Rail Mountable Output Module
* UL Recognized/Horse Power Rated (E46203)/CSA certified (38595)
* 4 kV Optical Isolation with LED Indicator
* Nominal Voltage: 24 VDC
* Minimum Voltage: 18 VDC
* Maximum Voltage: 32 VDC
* Drop-Out Voltage: 1 VDC
* Maximum Current: 13 mA
* Nominal Line Voltage: 5 - 48 VDC
* Minimim Line Voltage: 3 VDC
* Maximum Line Voltage: 60 VDC
* Max Off-State Voltage: 60 VDC
* Max Off-State Leakage: 10 A
* Maximum Rated On-State Current: 3 A
* Min On-State Current: 10 mA
* Max Surge Current: 5 A
* On-State Voltage Drop: 1.5 V
* 1 - Vynckier Miniature Enclosure with Clear Cover
* Outer Dimensions (H x W x D): 7" x 5" x 5"
These items are USED and are in good cosmetic condition. They have some scuffs/scrapes from usage and storage.
