Hardinge D9 wedge-type tool holder
HARDINGE D9 WEDGE-TYPE TOOL HOLDER
USED HARDINGE D9 WEDGE-TYPE TOOL HOLDER
A tool post is used for machining operations such as turning, chamfering, facing and grooving.
It mounts directly into a T-slot and uses 3/8 square shank tool bits. The tool bit can be adjusted to the height of the spindle centerline using the wedge assembly that is built into the holder. With this wedge arrangement, shims are not necessary to center the tool bit. The tool post is locked into place by using a hex key wrench in the tool post screw.
Once the tool bit has been set to the height of the spindle centerline, the holder can be loosened and moved in the T-slot without affecting the height of the tool bit.
KNOWN HARDINGE MACHINE USAGES: HLV/TFV, HSL, DSM/VBS, DV
