New jet lathe w/ 2-axis acu-rite dro 200S 321469
JET GH-1440ZX, Lathe With 2-Axis ACU-RITE DRO 200S Installed
Motor 7-1/2 HP, 230/460V 3 Ph Prewired 230V Spindle Bore 3-1/8" Spindle Mount D1-8 Number Of Spindle Speeds 12 Range Of Spindle Speeds 42 - 1800 RPM Range Of Inch Threads 1-5/8 - 72 TPI Number Of Inch Threads 61 Range Of Metric Threads .05 - 20 Number Of Metric Threads 24 Distance Between Centers 40" Swing Over Bed 14" Length Of Gap 12-1/4" Compound Slide Travel 5-1/8" Cross Slide Travel 9" Swing Over Cross Slide 7-5/8" Range Of Longitudinal Feeds .0015 - .0913 in./rev. Range Of Cross Feeds .0006 - .0365 in./rev. Number Of Longitudinal & Cross Feeds 122 Spindle Taper W/ Sleeve MT-7 (MT-5) Maximum Tool Size 1" X 1" Carriage Travel 35" Steady Rest Capacity 1/2" - 3-1/2" Follow Rest Capacity 3/8" - 7" Net Weight 5,700 lbs.
* Lathe w/ 2-Axis ACU-RITE DRO 200S Installed - 321469
