Psion teklogix 7035 hand-held 56 key 802.11 terminal
Psion Teklogix 7035 Hand-held 56 Key 802.11 Terminal Barcode Scanner
This terminal has been removed from a working environment and tested.
This terminal shows visible signs of use. The signs of use may include scuffs, scratches and/or sticker residue. It comes with 1 x 7.4V 2200mAh Lithium Ion Rechargeable battery P/N: 20605-003.
You will receive this item as pictured. No other accessories other than those pictured or mentioned in the listing will be included.
Unrivaled power, speed and flexibility
* Choice of single or dual Type II PCMCIA slots: one for your choice of radio support, the other for an ATA expansion card for mass data storage if required
* IEEE 802.11b open architecture direct sequence spread spectrum radios, narrowband radios and Mobitex wide area network radio support
* Terminal Development Kit provides programming tools for developing real-time or batch applications
* Solid support for advanced emulations including IBM 3270, IBM 5250, HP 2392, ANSI VT220 and HTML
* Application optimization to suit any ERP, WMS or supply chain software
* RS-232 peripheral port supports decoded and non-decoded scanners, serial printers and COM devices
* High-capacity battery; optional "big button " keyboard for gloved use in non-condensing environments down to -30C/-22F
To compete in the new economy, businesses must move products and services more rapidly than ever before. This requirement intensifies the need for real-time access to inventory management and supply chain information. The Psion 7035 hand-held, user-programmable computer offers the ideal solution, combining real-time accuracy, speed, ruggedness and ease of use. Lightweight and ergonomically designed, the Psion 7035 transmits and receives data in sub-seconds, and can stand up to the harshest conditions in warehousing, manufacturing, distribution or intermodal operations. And it 's also available as a low-temperature computer for non-condensing cold storage and yard applications down to -30C/-22F.
* Microprocessor: 32 bit AMD Elan SC400 486DX, 33 MHz
* Flash: 4 MB Flash, expandable to 8 MB
* RAM: 8 MB RAM expandable to 16 MB
* IEEE 802.11b 2.4 GHz Spread Spectrum, Direct Sequence
Data rate: 1, 2, 5.5 and 11 Mbps
* 403 - 512 MHz Synthesized Narrowband
Transmission power: 2 watts North America;
.01 to 2 watts International
Data rates: 9.6 or 19.2 kbps; Channels: 1 to 16
* Wired Equivalent Privacy (WEP)
* IEEE 802.1x support with Lucent WaveLAN radio
* LEAP support with Cisco 350 radio
* Two RS-232 serial ports, COM1 includes 16550 UART
* Peripheral port supports decoded and non-decoded scanners, serial printers, and other communication devices
* IrDA for wireless printing
* Internal beeper, volume and tone control
* Available in 36-key big button, 44-key multi-purpose and 56-key full alpha numeric formats
* All keyboards support remapping
* Up to 36 addressable function keys and 10 addressable/programmable macro keys
* 160 x 160 graphic monochrome transflective LCD VGA screen with automatic back-lighting and adjustable contrast
* Active area: 62mm x 62mm/2.44 x 2.44
* Font sizes supported: 5x10, 6x10, 8x10, 18x20, 18x26, 18x32, 9x20, 10x20, 10x26
* International language support including DBCS
* Standard high gain whip antennas on 2.4 GHz and narrowband models for maximum coverage
* Optional internal antenna for 2.4 GHz model
* At keyboard: 69mm/2.7 wide x 41mm/1.6 deep
* Maximum overall: 93mm/3.7 wide x 74mm/2.9 deep x 241mm/9.5 long
with battery, hand strap and 2.4 GHz 802.11b radio: 650g/23 oz
with integrated scanner add: 48g/1.7 oz
with pistol grip add: 110g/3.9 oz
Operating: 0C to 50C/32F to 122F
Storage (not incl. battery): -40C to 60C/-40F to 140F
Humidity: 5 - 95% relative humidity, non-condensing
* Freezer/Extreme temp. model
Operating: -30C to 50C/-22F to 122F
Storage (without battery): -40C to 60C/-40F to 140F
Humidity: 5 - 96% relative humidity, freezer condensing
* Std. & Freezer/Extreme temp. model
Drop Rating: Multiple 1.5m/5 drops to concrete
Vibration: 1.5G RMS PSD (Power Spectrum Density) on frequency range of 4 to 500 Hz
Rain/Dust: IEC 529, IP64 rating, NEMA 3 and 3S
* Fast swap, rechargeable 2200 mAh 7.2V Li-Ion battery pack, 2.5 hour recharge
* High reliability backup (approx. 5 min. during battery changing)
* APM (Advanced Power Management) compliant
* Accurate on-screen battery fuel gauge
* High performance standard range with configurable aiming dot
* Long range, with configurable aiming dot
* Advanced long range, with configurable aiming dot
* Safety (applies to chargers): UL 1950, CSA C22.2 No950
* EMC: FCC Part 15 Class B, EMC Directive 89/336/EEC
