Hubbell 2 pole, 3 wire grounding twistlock plug HBL2621
Hubbell 2 Pole, 3 Wire Grounding TwistLock Plug HBL2621
* Wiring Scheme: 2 Pole, 3 Wire Grounding
* Cord Dia.: .360"-.930" (9-24)
* Terminal Retainer Material: Clear polycarbonate
* Housing Material: Black nylon
* Cord Clamp Material: Natural (white) nylon
* Terminal Screw Material: #10-32 Brass (white finish on neutral screw when used) Multi-drive
* Cord Clamp Screw Material: Steel, zinc plated Multi-drive
* Dielectric Voltage Withstand: 2,000V minimum
* Current Interrupting: Certified for current interrupting at full rated current
* Temperature Rise: Max 30 C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of .75
* Cord Accommodation: Round portable service cords of diameters commensurate with the device rating as defined in UL Standard 62, CSA C22.2 No. 49
* Terminal Accommodation: 30A #10 AWG
* Terminal Identification: Terminals identified in accordance with UL 498 (X, Y, Z, White, Green)
* Flammability: HB or better per UL 94 or CSA 22.2 No. 0.6
* Operating Temperatures: Maximum Continuous 75 C Minimum -40 C (without impact)
