2PC 1X 10X passive oscilloscope probes rod tip leads
2pcs 1x 10x Passive Oscilloscope Probes Kit Rod Tip Lead
- 100% Brand New 2pcs 1x 10x Passive Oscilloscope Probes Kit Rod Tip Lead
- Two brand new 1X and 10X passive oscilloscope probes. They are high quality testing tools designed to make the most accurate measurements.
- To compensate the 60MHz probe, connect it to a 1kHz rectangle signal source (which most oscillosopes provide) and adjust it with the included screwdriver until you can see a clear rectangle signal on your measurement screen.
- Input Capacitance: 1X:85pF-115pF, 10X:14.5pF-17.5pF
- Compensation Range: 15pF-35pF
- Bandwith: DC-4MHz, DC-100MHz
- Working Voltage:1X:<150V DC, 10X:<300V DC
- Operating Temperature: -10 C - +50 C
- Non-operating Temperature: -20 C - +75 C
- Humidity: 85% (relative humidity)
