Control company mini-pump variable flow 3385
CONTROL COMPANY MINI-PUMP VARIABLE FLOW 3385
Please copy this link into your here for for operating instructions http:// /3384inst.pdf
precise low-flow deliveries. The squeezing action of the rollers on the tubing
progressively moves fluid through the tubing in advance of the rollers, resulting in
a peristaltic pumping action. The flow is proportionate to the speed of the pump
head and the inside diameter of the tubing, both of which can be varied. A
variable speed flow control and five different sized tubing assemblies provide fine
resolution with a wide range of flow rates. A PRIME (PURGE) setting is provided
12-volt wall adapter that plugs into a wall receptacle.
Tube I.D. Appr. Tubing Leng Appr. Flow Rate
1/50 , 0.5mm, 3.25 , 83mm, 0.03 0.06 ml/min
1/32 , 0.8mm, 3.5 , 89mm, 0.04 0.14 ml/min
1/16 , 1.6mm, 4.25 , 108mm, 0.25 0.8 ml/min
3/32 , 2.4mm, 4.5 , 114mm, 0.4 1.7 ml/min
3/16 , 4.8mm, 5.0 , 127mm, 1.7 4.6 ml/min
1/4 , 6.4mm, 4.375 , 111mm, 1.8 8.2 ml/min
* Control Company Mini-Pump Variable Flow 3385
If it's NOT in the picture, or in the description, then it will NOT be included in this sale. This also applies to power cords & A/C adapters.
You can also call us at (***)-655-0304 with your questions.
