Grundfosup 43-75F cast iron 1/6HP recirculator pump
Grundfos UP43-75F 1/6 HP Recirculator Pump (52722373)
The Grundfos UP43-75F 1/6 HP Recirculator Pump with cast iron pump housing.
SPECIFICATIONS - Grundfos UP43-75F 1/6 HP Recirculator Pump:
Motors: 2 Pole, Single Phase, 115 Volt
Maximum fluid temperature: 230 F (110 C)
Minimum fluid temperature: 36 F (2 C)
Maximum working pressure: 145 PSI
Connection: Flange - (2) 1/2" Diameter Bolt Holes
CONSTRUCTION - Grundfos UP43-75F 1/6 HP Recirculator Pump:
Spherical Seperator - Stainless Steel
Rotor, Impeller - Stainless Steel, EPDM, PRO, PFTE, Graphite
Terminal Box Cover, Motor Cover- Pa66/6
MOTOR - Grundfos UP43-75F 1/6 HP Recirculator Pump:
FEATURES and BENEFITS - Grundfos UP43-75F 1/6 HP Recirculator Pump:
Bronze and stainless steel construction.
Eliminates and prevents corrosive effects of fresh water.
Maintenance-free, low energy consumption, easy to install, quiet running.
Improved performance and efficiency.
Pre-program usage times to save power.
No additional wiring required.
Adds to savings by operating pump by sensing the water temperature with optional timer and aquastat.
