New T1 autonics rotary encoder enc-1-4-t-24 in box
AUTONICS Incremental measuring wheel type Rotary encoder ENC Series
By converting shaft rotation into electronic pulses, encoders are used to electronically monitor the position of a rotating shaft. The encoder s output pulses are counted and evaluated by a control unit to determine machine position and velocity, which provides exceptional accuracy and flexibility when controlling motion. The high mechanical and electronic operating speeds associated with optical encoders increase system speeds and accuracy, decrease cycle times, and boost overall productivity in the manufacturing environment. Autonics rotary encoders of various sizes and types offer high-quality and precise measuring of the operating position and speed of the rotating shaft, etc. for more precise control of the objects.
Incremental measuring wheel type Rotary encoder
* Suitable for measuring the length or speed of target moving successively by wheel type.
* The output waveform is proportional to the unit of international measurement type (Meter or inch)
* Power supply : 5VDC, 12-24VDC 5%
Wheel type Incremental Rotary encoder
Refer to the above table for resolution OR (Pic.5)
Output between A and B phase :
Low Load current : Max. 30mA, Residual voltage : Max. 0.4VDC
High Load current : Max. 10mA, Output voltage :
Max. 1 s (Cable length :2m, I sink = Max. 20mA)
12-24VDC 5% (Ripple P-P : Max.5%)
Max. 60mA (disconnection of the load)
750VAC 50/60Hz for 1 minute (Between all terminals and case)
Cable outgoing type, 200mm cable outgoing connector type
Depend on coefficient of friction
Max. allowable revolution : ( Note1) 5000rpm
1.5mm amplitude at frequency of 10 ~ 55Hz in each of X, Y, Z directions for 2 hours
-10 ~ 70 (at non freezing status), Storage : -25 ~ 85
( Note1) Max. allowable revolution > Max. response revolution Max. response revolution(rpm)=(Max. response freqency/Resolution) 60 sec Please select the resolution to make lower max. revolution than max. allowable revolution.
