Cnc router engraver drilling and milling machine 30200
CNC router engraver drilling and milling machine 30200
PVC Acrylics double-color sheet (ABS) Engineering Plastics bakelite wood, PCB etc.
* Max thickness of the material 65mm
* External dimension 550x400x350mm
* Working station area 450X240mm
* Frame material : 6061+6063 aluminum alloy
* Stepper motor 1.5A 57 motor two-phase 6 wires used
* Drive unit : 1204 Trapezoidal screw
* Slide glide unit : X axis 13 circular guide Y axis 16 circular guide Z axis 12 circular guide
* Engraving accuracy better than 0.06mm
* Resetting accuracy better than 0.05mm
* Idle load speed 4000mm/min
* Engraving speed 0 2000mm/min
* Spindle motor 200wDC motor low noise used , from USA servo motor
* Spindle speed 8000RPM 70V power)
* Driver board 0~2.5A adjustable 3 axis driver (3977chip 24V power
* Spindle power 200W/70V toriodal transformer + rectification)
* driving Power 24V6A switch power supply
