Hydraulic d/a handpump trailer kit lift 2.5 tonne 600MM
Hydraulic D/A Handpump Trailer Kit To Lift 2.5 Tonne - ZZ000805
This all in one hydraulic trailer kit consists of the following, easy to assemble, components which will allow you to lift a weight of up to 2.5 tonnes to a height of 600mm
* Hydraulic double acting handpump complete with tank and lever.
* 600mm stroke double acting cylinder.
* 2 x 3 metres of hydraulic hose.
* 5 litre cartons of hydraulic ISO32 oil
* Adaptors and washers to fit hoses to cylinder and powerpack.
TECHNICAL DETAILS ON DOUBLE ACTING HANDPUMP AS FOLLOWS:
* Handpump displacement 25cm3
* Max working pressure 350 bar
* Rubber protection for the piston
* 4/3 flow divider closed centre
* Complete with 1 litre steel tank and 600mm lever
TECHNICAL DETAILS ON DOUBLE ACTING CYLINDER AS FOLLOWS :-
* Closed Centre pin hole to pin hole 770mm
* Open Centre pin hole to pin hole 1370mm
* Max working pressure 200 bar.
Temperature -30 deg. C to 90 deg C
