30" x 7.5HP spdl tree millenium 4200 cnc vertical mill,
30" X 7.5HP Spdl Tree Millenium 4200 CNC VERTICAL MILL,
30" X Axis 7.5HP Spindle Tree Millenium 4200 CNC VERTICAL MILL, Anilam 1400 Control 3-AXIS,#40 Taper
TREE JOURNEYMAN RIGID RAM CNC VERTICAL MILL
MODEL: MILLENIUM 4200, S/N: 9-42-90-5263, NEW: 1992
TABLE WORKING SURFACE .................... 12" X 51"
NUMBER OF T-SLOTS ........................ 3
LONGITUDINAL (X) ................... 30"
CROSS (Y) .......................... 15"
VERTICAL, KNEE (MANUAL) ............ 17-3/4"
QUILL (Z) .......................... 6"
QUILL DIAMETER ........................... 4"
MAX/MIN DISTANCE, SPINDLE NOSE TO TABLE... 21-1/2" / 0"
THROAT DEPTH ............................. 14.8"
MAX UNIFORM TABLE LOAD ................... 800 LBS
SPINDLE SPEEDS, DIRECT DRIVE ............. 150 - 3500 RPM
SPINDLE TAPER ............................ CAT 40 V-FLANGE
X & Y AXES TRAVERSE RATE ................. 350 IPM
Z TRAVERSE RATE .......................... 250
X & Y AXES FEEDRATE RANGE, INF VAR ..... .1 - 250 IPM
Z AXES FEEDRATE ......................... .01 - 100 IPM
APPROXIMATE WEIGHT ....................... 5,200 LBS
APPROXIMATE DIMENSIONS ................... 98" X 110" X 86"H
- ANILAM 1400 CNC CONTROL w/ CONVERSATIONAL PROGRAMMING
- ELEVATION MOTOR FOR VERTICAL TRAVEL OF KNEE
- 7.5 HORSE POWER SPINDLE DRIVE MOTOR
