Thermo king thermoguard up-v whisper diagnosis manual
Thermo King Thermoguard uP-V Whisper Diagnosis Manual
Thermoguard uP-V Microprocessor Controller
SB-III SR+ King of the Road, SB-III SR+ Whisper, SB-III SR+ Rail Units, Super-II SR+ Rail Units, RMN-II SR+
The SB-III SR+ King of the Road units with uP-V controllers are one piece, self contained temperature control units designed for trailer application. The Thermoguard uP-V is a microprocessor based control system designed for use with transport refrigerationsystems.
Covers: Section 1 - Safety, special considerations for working on units equipped with microprocessors. Section 2 - Hardware Description, complete description of the control system hardware including the microprocessor, output, module, power supply, sensors, valves, and other control devices. Section 3 - Software Features, Includes information on the sequence of operation, programmable features and menu flowcharts. Section 4 - Operation. Section 5 -Diagnosis, includes both Alarm Code Diagnostics and Other symptom diagnostics.. Section 6 - Service Procedures, Step by step procedures to repair and program the microprocessor control system. Section 7 - Service Information. Section 8 - Diagrams and Schematics
In good Condition with minor shelf wear Covers are a little torn See picture
