Lexel 95 gas-ion laser w/power/rf plasma/mks baratron
LEXEL 95 GAS-ION LASER w/POWER/RF PLASMA/MKS BARATRON
SearchBy5 - 11165 | Location: J61 | By: Matty | Tester: Matty & ?? | Quan: 1 | List: 1 | Duplicate? False | Plan: H
Standard Relist: True | Size: 40x50x60 Weight: 400 | MGR: Cameron | Start: $0.00 | BIN: $999.96 | Type: Fixed Price
Sales: | Business & Industrial > Healthcare, Lab & Life Science > Lab Equipment > Lab Lasers & Photonics
MKS BARATRON 1 TORR PRESSURE TRANSDUCER (TYPE: 127AA-00001B)
MKS DIGITAL POWER SUPPLY READOUT (TYPE: PDR-C-1C)
RF PLASMA PRODUCTS RF MATCH CONTROLLER (MODEL: AMNPS-2A/CONTROLLER)
RF PLASMA PRODUCTS MATCHING NETWORK CHAMBER (MODEL: AMN-1001E)
RF PLASMA PRODUCTS RF POWER SUPPLY (800W-13.56Mhz) (MODEL: HFS-801S)0
Multiline 2-4 W argon or 3/4 W krypton; 208VAC/35A three-phase operation.
Beam diameter (@ 1/e2 points):
514.5 nm TEM00 (Argon) 1.3 mm
647.1 nm TEM00 (Krypton) 1.3 mm
Beam divergence3 (full angle):
514.5 nm TEM00 (Argon) 0.6 mrad
647.1 nm TEM00 (Krypton) 0.9 mrad
Amplitude power stability (1 hour period after 30 minute warm-up):
Optical resonator: Solid Invar rod structure
The Lexel 85 and 95 lasers can be operated in current or light control:
n Current regulation allows direct control of the current through the plasma tube via an external source.
n Light regulation provides the ultimate in laser output stabilization. A small portion of the light is sampled within the laser and compared to a reference signal in a differential circuit that automatically adjust the laser current to maintain a constant output.
This feature also allows for the light level to be modulated externally with a 10 volt signal.
Model 500 Temperature-Compensated Prism Wavelength Selector
Stable single line operation is achieved by Lexel ion lasers with the Model 500 prism wavelength selector. A full Brewster prism is utilized to achieve good separation of even the most closely spaced lines.
Model 502 Multiline Mirror Holder
This assembly holds the high reflector mirror for Multiline operation. This feature may be substituted for the Model 500 wavelength selector.
The laser is aligned accurately with the use of fine tuning knobs.
This feature permits the laser power supply to be turned on and off and the plasma tube to be started remotely.
This circuit automatically starts the plasma tube approximately 20 seconds after the power supply is turned on.
This multirange power meter continuously displays the output power of the laser.
More information on this item is available at: /laser_8595.htm
Dimensions: 40x50x60 inches - Weight: 400 pounds.
