> Sheldon R13,R15,R17 precision lathe operator's manual
Sheldon R13,R15,R17 precision lathe operator's manual
This is a reproduction, not a photocopy, of an original Sheldon Instruction Manual For R13, R15, R17 Precision Lathe Manual. This is a very professional instruction manual. I can see why they put it in a manual by itself without the parts list. This manual covers lubrication, setup, and operation of the lathe. Plus, it has the wiring diagrams. There is also a great troubleshooting check list; perfect for anyone that is having troubles with their lathe. This is an excellent manual and a must have for anyone that has this lathe.
I have the parts manual for this lathe as well.
Preliminary Instructions..........................1-3
Bolting.............................................4
Leveling..........................................4-6
Lubrication.........................................7
Electicals..........................................7
Headstock...........................................7
Geared Motor Drive..................................8
Selection of Threads and Feeds....................8,9
Apron and Carriage..................................9
Carriage and Compound Dials......................9,10
Accessories.....................................10-12
Telescopic Taper Attachment........................12
Headstock and Spindle Bearings.....................13
Motor Drive V-Belts................................13
Gear Box...........................................13
Lead Screw and Rod End Play........................14
Disassembly of Lead Screw and Feed Rod.............14
Carriage Gib.......................................14
Compensating Nut...................................15
Apron Clutched.....................................15
Motor Lubrication..................................16
Lubrication Checkoff List..........................17
Troubleshooting List...............................18
Wiring and Electrical...........................19-21
