Agilent 6632B dc power supply, pre-owned, nice
Agilent 6632B System Power Supply 0-20 Volts 0-5 Amps
Pre-Owned - Good Condition - No DOA Guarantee
* Output current: 0 to 5 A Programming Accuracy at 25 C 5 C
* Ripple & Noise (20 Hz to 20 MHz, with outputs ungrounded or with either terminal grounded)
* Voltage Normal Mode rms: 0.3 mV
* Voltage Normal Mode peak-to-peak: 3 mV
* Fast mode rms/ peak-to-peak: 1 mV/ 10 mV
* Current rms: 2 mA Load and Line Regulation
The Agilent 6632B System dc Power Supply is an ideal power source for demanding production test applications. This dc power supply offers high performance and precision measurements in a one-box solution. To reduce test-system development time and provide precision testing, the 6632B provides current measurement down to the microamp level. The 6632B also provides high-speed programming with under 4 millisecond response time.
This series of linear-regulated 80-100 W dc power supplies is designed to maximize the throughput of DUTs through the manufacturing test process. Both programming and measurement are optimized for speed. The active downprogrammer can sink up to the full rated current of the power supply, which quickly brings the power supply output to zero volts. The 6630B Series offers many advanced programmable features including stored states and status reporting. Programming is done using industry standard SCPI commands via the GPIB or RS-232. Test system integration is further simplified by using the VXIPlug&Play drivers. The optional relays simplify system design and troubleshooting.
for more info visit http://www.home.agilent.com/agilent/techSupport.jspx?pid=838596&pageMode=OV&cc=US&lc=eng
