5 channel usb oscilloscope portable pc based software
5 Channel USB Oscilloscope Portable PC-Based Software
- 100% Brand New 5 Channel USB Oscilloscope Portable PC-Based Software
- View signal voltages wherever you are with this easily portable 5 channel oscilloscope which plugs into your PC s USB port making this an ideal unit for both field and lab work.
- Use with electronic teaching equipment
- Examine and repair apparatus and appliances
- The portable oscilloscope is easily potable and takes its power directly from the USB port no batteries or other external power supply is required.
- 5 channel input and synchronised display
- Measure range automatically with 4 available modes
- Input capture (trigger) function
- Any channel may be set as the source of capture (trigger) signal
- Either rising or falling edge can be set to capture (trigger) signal
- Adjustable capture (trigger) signal level
- Saves data on hard disk and system will automatically summon data when started
- Computer connection: USB 2.0
- Signal input: BNC connection with universal oscillograph probe
- Frequency measurement range: 0Hz - 50KHz
- DIV array: Horizontal 16DIV * vertical 10DIV
- Adjustable voltage range: 10mV/DIV - 100mV/DIV '
- Max measuring voltage: 800MV, 8V when probe is X10
- Voltage measurement error: 2.5%
- Vertical baseline adjustable range: 6DIV
- Time domain adjustable range: 100uS/DIV - 8192S/DIV
- Data record and save capacity: 8388608 * 5
- Max data record and save time: 93 hours
- 1 x 5 Channel USB Oscilloscope Portable PC-Based Software
- 1 x High speed USB 2.0 cable
