90 ton x 10' chicago dreis & krump press brake w/cnc bg
90 TON x 10' CHICAGO DREIS & KRUMP PRESS BRAKE w/CNC BG
90 TON CHICAGO DREIS & KRUMP MECH. PRESS BRAKE
MODEL 810-L S/N L-20783 NEW 1982
TONNAGE NEAR BOTTOM OF STROKE ................ 90 tons
BENDING CAPACITY ............................. 10' x 10 ga
OVERALL BED SIZE ............................. 120"
DISTANCE BETWEEN HOUSINGS .................... 8'6"
STROKE ....................................... 4"
MOTORIZED RAM ADJ. ........................... 4"
SPEED ........................................ 40 / 5 SPM
OPEN HEIGHT .................................. 15"
THROAT ....................................... 8"
- AUTOMEC AUTOGAUGE CNC-99 FRONT OPERATED POWER BACK GAUGE
- 2 SPEED HI/LOW SELECT-A-SPEED
- 5 H.P. 3/60/230-460 VOLT MOTOR (CURRENTLY 460)
APPROXIMATE WEIGHT: 14,500 Lbs.
DIMENSIONS: 144" LR x 60" W x 96" High
TO SEE A VIDEO OF THIS MACHINE CUT & PASTE THE FOLLOWING
LINK!! http:// /watch?v=3to5d-Jpfk4
Click Here For More Dreis & Krump Machines
Click Here For More Press Brakes - PRESS BRAKES w/CNC BACK GUAGES(s)
Call Rick at (***) 873-6224 ext 7560
