South bend 17" gear head lathe manual parts list
This is a reproduction, not a photocopy, of an original South Bend 17-Inch Gear Head Parts List and Manual. This manual contains a complete parts list and exploded views of the lathe. This manual is very complete parts list for a South Bend, because all of the attachments and lathe parts are for this model only. The nice thing is they put them all in the same manual, unlike the 9-24 series. The parts section is very detailed and laid out in a nice arrangement. I wish all of the South Bends were setup this way.
Bed, Legs, Chip Pan Assembly...................................1-3
Lead Screw and Feed Rod Assembly........................4&5
Housing Assembly.....................................................6&7
Spindle Speed Shifters...............................................8&9
Sliding Gear Shaft....................................................9&10
Headstock Gears...................................................11&12
Brake Clutch Linkage............................................13&14
Reverse Bracket....................................................15&16
Oil Pump...............................................................17&18
End Gears Main Drive Shaft..................................19&20
Gear Box Housing Assembly.................................21&22
Shifting Mechanisms..............................................23&24
Cone Gears Assembly...........................................25&26
Tumbler Shaft........................................................27&28
Triple Shift Shaft....................................................29&30
Idler Shaft.............................................................29&30
Apron.....................................................................31-34
Saddle Assembly...................................................35&36
Compound Tool Rest............................................37&38
Tailstock...............................................................39&40
Taper Attachment.................................................41&42
Control Rod Assembly...........................................43&44
Apron and Saddle One Shot Oilier.........................45&46
Follower Rest...............................................................47
Steady Rest..................................................................48
Coolant Pump.......................................................49&50
Splash Pan............................................................51&52
