High voltage pnp transistor MJE5731 to-220 nos lot 10
High Voltage PNP Silicon Transistor MJE5731 ....selling in lots of 10
. . . designed for line operated audio output amplifier,
power supply drivers and other switching
300 V to 400 V (Min) VCEO(sus)
Popular TO 220 Plastic Package with shorter leads
PNP Complements to the TIP47 thru TIP50 Series
1.0 AMPERE POWER TRANSISTORS PNP SILICON 300 350 400 VOLTS
DATASHEET HERE: http://www.datasheetcatalog.org/datasheet2/8/0iq2ji60k3k5wda4khq30xoxzhcy.pdf
temperature and second breakdown. Safe operating area curves indicate IC VCE limits
of the transistor that must be observed for reliable operation; i.e., the transistor must not
be subjected to greater dissipation than the curves indicate. The data of Figure 5 is based
C; TC is variable depending on conditions. Second breakdown pulse limits
are valid for duty cycles to 10% provided TJ(pk) 150 C. TJ(pk) may be calculated from the
data in Figure 6. At high case temperatures, thermal limitations will reduce the power
that can be handled to values less than the limitations imposed by second breakdown.
