New darkfield condenser+100XPLAN objective 4 microscope
Advanced Darkfield Condenser + 100X Darkfield Plan Objective Lens
The darkfield microscopy is a technique to observe unstained transparent specimens in a dark viewing field background, but suffers low light intensity, ie. the dark viewing field is too dark, even with the brightest illumination.
The problem is resovled by our newly designed darkfield condenser, which provides much brighter viewing field then the ordinary one. Two images taken from the two darkfield condensers are put here for comparison.
Microscope Image A191BOIL Microscope Image A191OIL1
* Darkfield condenser: NA 1.36-1.25
* Condenser mounting size: 37mm in diameter
* Darkfield objective: Plan 100X/1.25-0.5 160/0.17, w/ built-in iris diaphragm, oil, spring loaded
* One plan 100X darkfield objective lens
Other Darkfield condenser available:
Click the button above to see the list of microscopes compatible with this product A191BOIL
