Anritsu 68147B 20 ghz synthesized sweep generator w/2A
This sale is for an Anritsu/Wiltron 68147B 10 MHz to 20 GHz Synthesized Sweep Generator
with Option 2A Step Attenuator. Tested in our lab and works well.
Independent ISO9001 Calibration available inquire.
Frequency Switching Time: 40 ms
Time base stability: 0.00000002 /day
Minimum Single-Side-Band Noise: -96 dBc/Hz
Maximum Single-Side-Band Noise: -66 dBc/Hz
Modulation: External AM, FM, Pulse
Sweep Modes: Alternate, Analog, Power, Step
Power: 90 to 132 Vac or 180 to 264 Vac 49 to 440 Hz
Ultra-low SSB phase noise; - 100 dBc at 10 KHz offset from 10 GHz
0.01 to 20 GHz frequency coverage in a single coaxial output
Waveguide extensions to 110 GHz
+11 dBm maximum power (with attenuator option 2A), -125 dBm min. power
Internal AM,FM, phase and pulse modulation
User down-loaded complex modulation
Step, analog , power, alternate, master/slave sweep modes
User level flatness correction
