Flir thermacam P65 high performance infrared camera
This FLIR Systems ThermaCam P65 is in excellent condition. I guarantee you will be satisfied with this camera package, it is an incredible system. Please download the user manual by clicking HERE, and the FLIR overview brochure by clicking HERE. You can also download the Quickview software manual by clicking HERE.
If you have any questions, please feel free to ask and I will do my best to get them answered as soon as I can. The only flaw of note is the included bluetooth headset is missing the cover for the microphone.
This ThermaCAM P65 listing includes:
POWER SUPPLY INCLUDING CABLE
All of the descriptive text that follows, can be found in better form if you download the PDF's above. If you have done that already, just scroll down to the photographs. A full list of specs are located right before the photographs begin.
Please check my other listings for additional FLIR cameras, and lenses, (click on "see other items" at the top right hand corner of this listing underneath my username, if you can not find them listed they have already been sold).
The FLIR ThermaCAM P65 automates capture, analysis, and archiving of thermal images. Utilizing Bluetooth wireless technology, it offers voice recording up to 30 sec with each image. Camera automatically tracks position of hottest spot in image, indicates temperature, and calculates difference between measurement points. It includes USB and IrDA connectivity, as well as FireWire connectivity for transfer of digital video at up to 800 megabits/sec. Images are stored as radiometric JPEGs.
RADIOMETRIC JPEG IMAGE STORAGE
The ThermaCAM P65 has been designed in cooperation
with maintenance professionals who use an infrared camera
several hours a day. This has led to a system that is not only
very user-friendly but also extremely light and easy to carry.
Including battery and LCD display, the ThermaCAM P65
weighs less than 2 kg, making it the lightest full-featured
infrared camera on the market.
Designed for use in harsh environments, the ThermaCAM P65
is built to withstand shocks (25G) and vibration (2G). It is dustand
watersplash-proof and carries the industrial IP 54 rating.
No matter what the situation, the ThermaCAM P65 is always
easy to handle. Look at the object through the high-resolution
TFT color viewfinder, or carry the camera by its handle while
viewing the infrared image on the LCD display. The camera
control buttons are always right underneath your fingers.
A lamp can be connected to the camera to illuminate dark
areas, e.g. when shooting visual images in-door, so that you
always produce clear, high-quality visual images to document
The LCD display, with all necessary remote control buttons, is
detachable. It allows you to view images while the camera is
positioned in hard-to-reach areas.
PRECISION TEMPERATURE MEASUREMENT
The ThermaCAM P65 delivers unmatched temperature measurement
accuracy. A thermal sensitivity of 0.08 C results in
clear noise-free images (320 x 240 pixels).
A low thermal sensitivity not only offers you the possibility to
see the smallest of temperature changes. It also means you
get crisp, very detailed high-resolution images which cannot
be obtained by less sensitive cameras.
The ThermaCAM P65 takes high-definition 14-bit thermal images.
At the same time, it records visual images with its built-in digital camera.
FLIR Systems has recognized the importance
of having a visual image as a reference
Engineers who detect problems with the
infrared camera are often not the same
people as those who have to repair the
defects. The ability to view the environment
in which a problem is located on a
visual image makes the job a lot easier.
With the ThermaCAM P65, all this is done
automatically. There is no need to carry
The integrated Laser LocatIR , activated
at the touch of a button, helps you to safely
and quickly associate a hot spot shown
on the IR image with the problem area on
The operator can set a maximum temperature
in the camera. If the P65 is pointed
to an object and this temperature is
exceeded, the camera will produce an
Calculates the temperature difference
between measurement points directly in
The camera will automatically indicate the
temperature and the position of the hottest
Useful when scanning moving targets
such as motors, conveyor belts, ...
The camera can record up to 35 seconds
of video in an AVI-file. This AVI-file can be
replayed in the camera or on a PC for
VOICE RECORDINGS WITH BLUETOOTH
The camera can store up to 30 seconds of
voice comment with each image. A
Bluetooth connection allows for wireless
connection between the camera and the
earpiece with integrated microphone. The
wireless earpiece eliminates all cable
connections between the operator and the
camera, increasing operator safety.
No need to re-set all your preferred camera
settings one by one if a colleague has
used the camera. You can easily upload
your own favorite camera settings (color
palettes, spots or areas, ...).
From now on, you do not need to introduce
all fields in the text comments boxes
over and over again. Just copy the text
comments from one image to another and
change only what needs to be changed.
Tailor your color palettes to your applications
and upload them in the camera.
Internal RAM-memory for burst and
The ThermaCAM P65 can store up to 600 images on its
internal RAM-memory. Radiometric images can be stored at a
rate between 25 Hz and 0.5 Hz allowing between 24 seconds
and 20 minutes recording time. Ideal when scanning moving
targets such as motors, conveyor belts, ...
In-camera play-back allows you to view recorded images or
sequences without the need to carry a PC. The recorded data
can also be easily transferred to a PC for further analysis and
editing in the optionally available ThermaCAM Reporter
For those applications that do not require radiometric data, the
camera can also record up to 35 seconds of moving images
in an AVI-file. No special software needed. Anyone can access
The ThermaCAM P65 saves images as
fully radiometric JPEGs. These images,
together with measurements, plus voice
and/or text annotations, are stored either
on a removable compact FLASH PC card
or in the camera s FLASH memory.
Images can easily be downloaded
from the camera using the ThermaCAM
QuickView software which is supplied as
Field of view/min focus distance 24 x18 /0.3 m (with 35 mm lens)
Spatial resolution (IFOV) 1.3 mrad
Thermal sensitivity 0.08 C at 30 C
Image frequency 50/60 Hz non-interlaced
Electronic zoom function 2,4,8 interpolating
Detector type Focal Plane Array (FPA), uncooled microbolometer 320 x 240 pixels
Digital image enhancement Normal and enhanced
Built-in digital video 640 x 480 pixels, full color
Video output RS170 EIA/NTSC or CCIR/PAL composite video, IEEE-1394 FireWire DV-output
Viewfinder Built-in, high-resolution color LCD (TFT)
External display 4 LCD with integrated remote control
Temperature range -40 C to +500 C, (+40 F to +932 F), in 2 ranges
Up to +1500 C (2732 F) or +2000 C (3632 F), optional
Measurement mode Spot/manual (up to 10 movable), automatic placement and reading
of max. and min. temperature within area.
Area (circle (5) and/or box (5), movable), isotherm (2), line profile, Delta T
Atmospheric transmission correction Automatic, based on inputs for distance, atmospheric temperature
Optics transmission correction Automatic, based on signals from internal sensors
Emissivity correction Variable from 0.1 to 1.0 or select from listings in pre-defined materials list
correction Automatic, based on input of reflected temperature
External optics/window correction Automatic, based on input of optics/window transmission and temperature
Type Removable Flash-card (256 MB) Built-in Flash memory (50 images)
Built-in RAM memory for burst and AVI recording
File formats - Thermal Standard JPEG, 14 bit measurement data included
File formats - Visual Standard JPEG (including movable marker) linked with
Voice annotation of images 30 sec. of digital voice clip stored together with the image -
Text annotation of images Predefined text selected and stored together with the image
Field of view/min focus distance 7 x5.3 /4 m (with 122 mm lens)
12 x 9 /1.2 m (with 71 mm lens)
45 x 34 /0.1 m (with 18 mm lens)
80 x 60 /0.1 m (with 9 mm lens)
200 m close-up (64 mm x 48 mm/150 mm)
100 m close-up (34 mm x 25 mm/80 mm)
50 m close-up (15 mm x 11 mm/19mm)
18 m close-up (6 mm x 4 mm/7mm)
LCD Display Shows status of battery and storage media. Indication of power,
communication and storage modes
Type Semiconductor AlGaInP Diode Laser: 1mW/635 nm red
Type Li-Ion, rechargeable, field replaceable
Operating time 2 hours continuous operation
Charging system in camera (AC adapter or 12 V from car) or 2 bay intelligent charger
External power operation AC adapter 110/220 V AC, 50/60 Hz or 12 V from car
(cable with Std plug: optional)
Power saving Automatic shutdown and sleep mode (user selectable)
Operating temperature range -15 C to +50 C (5 F to 122 F)
Storage temperature range -40 C to +70 C (-40 F to 158 F)
Humidity Operating and storage 10% to 95%, non-condensing
Shock Operational: 25G, IEC 68-2-29
Vibration Operational: 2G, IEC 68-2-6
Weight 2.0 kg incl. battery and top handle (includes remote control, LCD, video
camera and laser) 1.4 kg excluding battery and remote control with LCD
Size 100mm x 120mm x 220 mm (3,9 x4,7 x8,7 ) camera body
FireWire IEEE-1394 FireWire output (DV only)
USB / RS-232 Image (thermal and visual), measurement, voice and text transfer to PC
Remote control Top carrying handle with video camera, Laser LocatIR and LCD
