Sumitomo type-65M24 fusion splicer **usa model**
The Type-65M24 sets a new standard for productivity for high fiber count applications. With its reduced size and weight it is also designed for complete portability. With 30 mph wind protection and a compact size, it can splice in any environment. Utilizing precision v-groove alignment, the Type-65M24 can be used for all types of ribbon and single splicing with an optimum arrangement for ease of use in aerial and taut-sheath applications.
A patented fiber viewing system simultaneously focuses on up to 24 fibers at a time and maintains equal resolution across all fibers for improved accuracy of splice loss estimations. The high-speed, high-resolution image processing system automatically evaluates the fibers in two planes (X and Y-axes) for cleaver-end-face quality, cleave length irregularity, and fiber offset to screen the most likely causes of high loss splices.
The Type-65M24 also has programmable power management functions for longer battery operation, a large color monitor, one of the fastest built-in fiber protection sleeve heaters available, and ultra-fast 50 second 24 fiber mass splicing!
Fiber Type: SMF, MMF, DS and NZ-DSF
Coating Diameter: Ribbon: 250 m Single: 250 and 900 m
Number of Fibers SM: 1, 2, 4, 5, 8, 10, 12, 16, 24 MM: 1, 2, 4, 6, 8, 12 NZ-DSF: 1, 2, 4, 6, 8, 10, 12, 16, 24
Typical Splice Loss, Identical Fibers: SMF: 0.05dB MMF: 0.03dB DSF: 0.07dB NZ-DSF: 0.08dB
Number of Fusion Condition Settings - 3 Fiber Profiles With 7 Pre-set Programs Each. Maximum of 48 Programs.
Splice Parameters 5 Parameters for Each Program
Number of Heater Condition Settings - 10
Typical Splice Cycle Time: 12 Fibers: 30 Seconds (Set to Loss Estimation) 24 Fibers: <50 Seconds
Splice Data Storage - 250 Splice Data Points
Fiber Cleaver (24-Fiber CLeaver FC-M24-C)
Thermal Jacket Remover (JR-5M24)
24 Fiber Ribbon Holders (RHS-24) and 250um Single Fiber Holders (RH-250) and 12-Fiber Ribbon Holders (FHM-12)
Alchohol Dispenser Bottle (HL-2)
* Compact, Lightweight Design and Front to Back Work Flow System Simplifies Splicing in Confined Areas(i.e. Aerial, Taut-Sheath)
* Simultaneous Focusing on Up to 24 Fibers at a Time
* 5.6 Color LCD Monitor Display with On-Screen Guide Eases Operation In a Field Environment
* Lower Power Consumption With Built-In Power Management
* Automatic Splice and Loss Estimation In Less Than 50 Seconds for 24-Fiber Ribbon
This unit is size, in inches, is 5.9W x 5.9D x 6.5H, with a weight of 8.8 pounds, input 100 to 240V AC, 12V DC
