8" dia. x 72" ajax center vibrating tubular feeder
8" DIA. X 72" AJAX CENTER VIBRATING TUBULAR FEEDER
MANUFACTURED BY AJAX, RENOLD CORPORATION, WESTFIELD, NY. AJAX SHAKER SIZE 10DFH, NUMBER 14135. SERIAL NUMBERS 0172 AND 0173. UNITS ARE 8" DIAMETER CARBON STEEL PIPING, PROBABLY SCHEDULE 40. CENTER OF FEED TO CENTER OF DISCHARGE IS 72". UNITS ARE FOUR LUG CABLE SUSPENSION DESIGN. INLET AND OUTLET ARE VERTICAL, PLAIN ENDS. UNITS ARE DRIVEN BY A 1 HP, 1750 RPM, 208-230-460-3 LEESON MOTOR. SERVICE MOTOR IS 1.15. V-BELT DRIVE AND THE DRIVE IS UNDERNEATH OF THE HORIZONTAL TUBE.
