Thornton 770MAX meter, model 775-LA1, 4 analog outputs,
This listing is for a Thornton 770MAX Meter, Model 775-LA1, 4 Analog Outputs, 4 Relays, LCD, AC 100-240V 50-60Hz NIB
* Thornton 770MAX Meter, Model 775-LA1, 4 Analog Outputs, 4 Relays, LCD, AC 100-240V 50-60Hz NIB
* Be sure to look at my other listings for sensors (Listings)
The 770MAX is an advanced instrument for on-line measurement and control in most water treatment, process, and wastewater applications. Thornton made history with the 770PC, the original multiparameter instrument for pure water monitoring. The next generation, 770MAX Multiparameter Analyzer/Transmitter brings this innovative technology to greater heights, with its high accuracy, exceptional ease of use and multipoint, multiparameter capabilities.
A true multiparameter analyzer/transmitter, the 770MAX provides concurrent monitoring of as many as six individual sensors and transmits analog and digital data, when connected to separate system controllers and acquisition devices.
* 6 Sensor Channel Inputs (4 Smart Sensors, 2 Pulse Flow)
* 4 or 8 Analog Outputs (0/4-20mA)
770MAX accepts input from eight sensor-types from which it computes values in any of 35 different units. This extensive variety is supported by a multi-line scrolling display and the instrument's "custom names" feature, which allows labeling of each measurement.
770MAX was designed from the bottom up for simplified specification, installation, startup, calibration, operation and maintenance. This design includes:
* Smart Sensors for automated start up
* Plug-in connectors for all inputs & outputs
* Universal power supply: 100-240 V, 50-60 Hz
* Single 1/4 DIN case houses all options
* Sealed rear cover accessory
* Automatic calibrator accessory
The 770MAX utilizes patented Smart Sensor technology. Every Thornton Smart Sensor contains a non-volatile memory chip (NVRAM) embedded in its electronic circuitry which stores identification and calibration information specific to that sensor. Upon connecting a Smart Sensor to a 770MAX, the instrument automatically recognizes its type and becomes the "meter" for that parameter. The sensor is ready to transmit data from the fluid system to the MAX for processing. A more specific example of Thornton's commitment to accuracy is the instrument's industry-leading 4-wire resistivity measurement technology, which delivers the highest accuracy and lowest limit of contamination detection. The 770MAX achieves this level of performance through unique sensor calibration techniques in its manufacturing process and cutting-edge temperature compensation methods.
