> 5,193 square feet griffin dust collector
5,193 square feet griffin dust collector
5,193 SQUARE FEET GRIFFIN DUST COLLECTOR
MANUFACTURED BY GRIFFIN ENVIRONMENTAL, SYRACUSE, NY. MODEL JA-294-CG. GRIFFIN DRAWING # .GA3-20632-J-01. TOP REMOVAL, WALK IN PLENUM. 21 BLOW PIPE HEADER WITH SOLENOIDS, 14 FILTERS PER ROW, 5.625" DIAMETER X 144. TOP BAG REMOVAL WITH 294 BAGS. S.O. NUMBER 20632. 5,193 SQUARE FEET FILTER AREA. ORIGINAL DESIGN WAS WITH A/C RATIO 2.88 1. PRESSURE DIFFERENTIAL CONTROLLERS. 21 EXPLOSION PANELS WITH BRIXTON LATCHES, VARIOUS SIZES ON SIDES OF COLLECTOR. COLLECTOR IS APPROXIMATELY 40.5 FEET TALL OVERALL HEIGHT X 10'- 7" WIDE X 15'-2" WIDE. FEATURES INCLUDE SPRINKLER HEADS, HINGED 18" X 60" ACCESS DOORS IN CLEAN AIR PLENUM, 18, 36" X 48" PRESSURE RELIEF DOORS HIHGED TOP, SPRING LATCH BOTTOM RATED FOR ST-3;3, 30" X 48" PRESSURE RELIEF DOORS HINGED TOP, SPRING LATCH BOTTOM RATED FOR ST-3, NEMA 4, 115 VOLT SOLENOID ENCLOSURES, 1-1/2" DIAPHRAGM VALVES ( 21), HEADER PIIPE, 6" DIAMETER WITH PRESSURE GAUGE, APPROX 70 DEGREE SLOPING HOPPER, DESIGN PRESSURE IS 30" W.G. NEGATIVE, DESIGN TEMP IS 250 F MAX. MATERIAL: WALLS AND TUBE SHEET ARE 10 GAGE; BLOW PIPES: GALVANIZED STEEL. CAGES: GALVANIZED STEEL. VENTURIS: ALUMINUM. DIAPHRAM VALVES: ALUMINUM. PAINT: 1 COAT INTERIOR; 2 COATS EXTERIOR. GROSS WEIGHT OF COLLECTOR: 28,000 LBS APROXIMATE. NOTE: SUPPORT STEEL INCLUDING HANDRAIL, INTERMEDIATE PLATFORMS, LADDERS, ETC AVAILABLE AT AN ADDITIONAL $ 12,500.00. UNIT HAS BEEN DISMANTLED AND RELOCATED TO OUR MILLWOOD, WV YARD.
