Case service shop manual - 500 load king & W5A loader
SECTIONS COVERED IN THIS MANUAL:
SPECIFICATIONS FOR 188 DYNACLONIC DIESEL & 188 SUPR-TORQ GASOLINE ENGINES,
SERVICING THE ELECTRICAL SYSTEM WITH WIRING DIAGRAMS,
SERVICING THE CYLINDER HEADS, VALVE SYSTEMS, ROCKER ARMS, ON DYNACLONIC DIESEL ENGINES,
SERVICING THE CYLINDER HEADS, VALVE SYSTEMS, ROCKER ARMS ON SUPR-TORQ SPARK IGNITION ENGINES,
SERVICING THE ASSEMBLIES IN THE ENGINE BLOCK,
SERVICING THE TIMING GEAR COVER, FUEL INJECTION PUMP DRIVE & GOVENOR,
SERVICING THE HYDRAULIC CYLINDERS & LOADER CHASSIS BUSHINGS,
* SERVICING THE VDP-12 HYD. CONTROL VALVE,
* SERVICING THE 2000 SERIES GEAR TYPE HYDRAULIC PUMP ON 2-WHEEL DRIVE LOADERS,
* SERVICING THE POWER STEERING CYLINDER & CONTROL VALVE,
* SERVICING THE STEERING GEAR BOX AND REAR AXLE,
* SERVICING THE POWER STEERING PUMP
* SERVICING THE HYDRAULIC POWER SHUTTLE,
* SERVICING THE 4-SPEED MECHANICAL TRANSMISSION, DIFFERENTIAL, FINAL DRIVE and DIFFERENTIAL BRAKES
Pages: 325 +/- in GOOD to VERY GOOD CONDITION !!!!
