New 1760RB 17" x 60" heavy duty precision engine lathe
1760RB 17" x 60" Heavy Duty Precision Engine Lathe NEW
* 2.28 spindle bore. 17 swing over bed allows you to work on large variety of parts. There is a removable gap to accommodate even larger diameter parts.
* Spindle support by 3 high precision bearings ensure smooth running operation and high accuracy. Bearings provided by FAG (German brand).
* Turcite-B bearing material between the surfaces of the saddle and bed.
* Bed ways are hardened and precision ground to ensure most accurate movement and wear resistance.
* Chromium molybdenum steel gears in headstock are hardened and precision ground for extra durability and low noise.
* Adjustable lubrication system with Auto/Manual settings: Leave it on auto or pump the ways with an extra shot of lubrication oil on demand.
* 11 13/16 EXTRA WIDE bed ways on heavy one-piece cast iron base provide stability and rigidity to take deeper cuts.
* Inch/Metric Universal GearBox allows switching between inch and metric threads without change gear.
* Mechanical overload device in carriage.
* Heavy duty tailstock has dual clamping mechanism for extra rigid connection to bedways, to better resist forces from heavy drilling.
* Low voltage controls for extra safety.
0.0011 ~ 0.0633 / rev (42 settings)
0.031 ~ 1.7mm /rev (42 settings)
0.00033 ~ 0.01837 (42 settings) / 0.014 ~ 0.784mm (42 settings)
Total Travel of Tailstock Quill
1. 8 3-Jaw Chuck & Back Plate
2. 10 4-Jaw Independent Chuck & Back Plate
8. Chuck Guard with Micro Switch
9. Complete Coolant Equipment
10. One Piece Casting Iron Base
12. Inch/Metric Universal Gearbox
13. Auto Longitudinal Feed Stop
14. Change Gears for DP & MP Threads
15. Full Length Splash Guard
18. Centers and Center Sleeves
20. Operation Manual & Parts List
1. Digital Readout (DRO) NEWALL $1640
2. Digital Readout (DRO) SONY $1520
6. Taper Turning Attachment (TTA)
7. 5C Collet Closer & Collets
8. Quick Change Tool Post with 5 Holders $436
