Belden 1672A 75 ohm high-freq cable conformable coax
Belden 1672A 75 Ohm High-Frequency Cable Conformable Coax Cable InterCon CB-16724
$2,207.00 (1k ft min) (1 week lead time) (OEM 11/24/09 MQF)
CDAX, Conformable Belden 16724 / 1672A
29 AWG solid .011" silver-coated copper-covered steel conductor, TFE Teflon insulation, copper-tin composite shield (100% coverage), unjacketed.
* Conductor Material: SCCCS Silver-coated Copper-coated Steel
* Insulation Trade Name: Teflon
* Insulation Material: TFE Tetrafluoroethylene
* Insulation Diameter: 0.062
* Outer Jacket Material: Unjacketed
* Outer-Shield Material: Layer 1: Copper-Foil Tape, Layer 2: Tin-Filled Composite Braided
* Overall Nominal Diameter: 0.087
* Operating Temperature Range: -70C to +200C
* Nom. Inductance: 0.109uH/ft
* Nom. Capacitance Conductor to Shield: 19.5 pF/ft
* Max Operating Voltage: 300V RMS (UL)
* Max Operating Volateg: 900V RMS (Non-UL)
