Astec mvp series, 600W power supply with 3-outputs
See complete specifications at: http://ohm.bu.edu/~hazen/DataSheets/Astec/MVP_Series.pdf
Be confident that you are doing business with someone who Knows Electrical Power Systems and How to Test Them
ASTEC MVP Series - 600Watt Power Supply.
It is used on several AVO Multi-Amp test sets; (For Example, the EPOCH microprocessor based relay test set)
* Current share on all outputs with ratings of 10 A or greater
* Remote sense on all outputs with ratings greater than 2 A
* Overload protection on all outputs
* Voltage adjustment on all outputs
* Margining on all single output modules
* Input-OK-signal and status indicator LED
* Global DC OK signal and status indicator LED
* Global and individual module inhibits/enable
* Forced air cooling, field replaceable fan
* IEC EN61000-3-2 harmonic distortion compliance
* CISPR 22, EN55022 Curve B conducted / radiated EMI
* European CE Mark requirements
* Optional VME timing and system DC OK module
* Low leakage option for medical applications
* Immunity - EN61000 -4, -2, -3, -4 & -5 Level 3
* Operating temperature: -20 C to 50 C (start @ 0 C) (derate each output linearly to 50% at 70 C) (-20 C to 40 C max. with rear air option)
* Shock/Vibration: Mil-Hdbk 810E
* Humidity: 95% non-condensing
* Storage temperature: -40 C to +85 C
* Temperature coefficient: 0.02% per C
* Cooling: Internal DC fan (Field replaceable)
* CSA CSA22.2 No. 234 Level 5
* BABT Compliance to EN 60950, BS 7002
