3/8" 6 way hydraulic diverter valve max 300 bar
3/8" 6 WAY HYDRAULIC DIVERTER VALVE MAX 300 BAR
3/8" 6 WAY HYDRAULIC DIVERTER VALVE.
Connect P and P' to the 2 pressure flows, Ports A and B to the first actuator and ports A' and B' to the second actuator. With lever in position 1, P is connected to A and P' to A'; with lever in position 2, P is connected to B and P' to B'. With lever in central position all ports are connected to each other (open centre).
