Central Machinery 2 Horse Power Heavy Duty Milling/Drilling Machine
Here is a Central Machinery Heavy Duty Milling/Drilling Machine with an upgraded 2 HP motor. This universal heavy duty milling/drilling machine is constructed from rigid cast iron and steel to ensure maximum precision. This machine is in complete working order except for some missing handles/knobs. The slide table works perfectly in longitude and cross travel. Below are the detailed specs.
Drill capacity: 1-1/4"; Face mill capacity: 3"; End mill capacity: 3/4"; Swing: 15-7/8"; Spindle stroke: 5"; Column diameter: 4-1/2"; Spindle speeds (RPM): 120-200-250-290-400-(***)-820-1090-1245-1520-1820-2500; Spindle taper: R8; Longitudinal table travel: 19-3/4"; Cross table travel: 7-3/8"; Table: 8-1/4" x 28-3/4"; Height: 43-1/2"
Please see the 3rd picture for motor details.
