Dual boom stand binocular stereo microscope 20X-40X-80X
XG324NH Binocular Stereo Microscope with Boom Stand Image 1
XG324NH Binocular Stereo Microscope with Boom Stand Image 2
XG324NH Binocular Stereo Microscope with Boom Stand Image 3
XG324NH Binocular Stereo Microscope with Boom Stand Image 4
XG324NH Binocular Stereo Microscope with Boom Stand Image 5
XG324NH Binocular Stereo Microscope with Boom Stand Image 6
XG324NH Binocular Stereo Microscope with Boom Stand Image 7
XG324NH Binocular Stereo Microscope with Boom Stand Image 8
XG324NH Binocular Stereo Microscope with Boom Stand Image 9
XG324NH Binocular Stereo Microscope with Boom Stand Image A
XG324NH Binocular Stereo Microscope with Boom Stand Image B
Binocular 20x~40x~80x Stereo Microscope
with Dual-Bar Sturdy Boom Stand
XG324NH Binocular Stereo Microscope with Boom Stand Image R
* Sturdy boom stand provide extra working space and secure microscope head
* Sharp stereo erect images over a super wide field view
* Interpupillary distance: 2-3/16" ~ 2-15/16"(55~75mm)
* Adjustable inter-pupillary distance to fit anyone's eyes
* Locked-in eyepieces avoid eyepiece dropping
* Capable to add auxiliary lenses and ring lights
* Mounting size of auxiliary lens and ring lights: 48mm female thread
Magnifications and Objectives:
* Eyepieces: wide field WF10X/20 and WF20X/10
* Long working distance: 80 mm (3-1/8")
* Metal rack and pinion mechanism
* Dual horizontal bars allow large working area and secure microscope body
* 300 horizontal rotatable movement
* Body holder can be horizontally pan rotating
* Matching diameter for microscope body: 75-77mm
* Body holder dimension: 77mm+
* Body holder can flip up to 90
* Height of boom stand: 16~3/4" (42.5cm)
* Boom travel stroke: 18" (20.3cm)
* Diameter of boom bar: 1-1/4" (3.2cm)
* Base Dimension: 9 "x 9" (23cmx23cm)
* Base height: 1-3/4" (4.5cm)
* Dimension: 19-5/8 " x 18-1/2" x 14-1/2" (50cm x 47cm x 36cm)
* Binocular stereo microscope head
* A pair of WF10X/20 eyepieces
* A pair of WF20X/10 eyepieces
* A pair of rubber eyeshields
* A full set of universal boom stand with rack and pinion focus adjustment (A902)
Optional Accessories (sold separately):
* Fluorescent ring light for brighter even illumination
* Gooseneck fiber cold light for flexible lighting angles
* Fiber ring light with low heat and adjustable intensity
* Gem jewel tweezers (be used on a mechanical stage)
* 0.5X auxiliary objective for increasing working distance and field of view
* 2.0X auxiliary objective for having higher power levels
* USB camera eyepiece for computer connection
* Mechanical specimen stage for smooth movement
Click the button above to see compatible part list for this product XG324NH
