View engineering ccm metrology system voyager 12X12
This is a High-Performance Floor Stand Metrology System in working condition.
The View VoyagerT Model V12x12 is the highest performance non-contact, automated dimensional metrology system available today. In all critical areas - accuracy, repeatability, reproducibility, inspection throughput, programmability, machine-to-machine correlation, and reliability - the system delivers for the most demanding applications.
* Windowsr operating system-easy to program and use.
* PC Computer w/ Windows XP and Color printer
Measuring Accuracy (at 20 C) U2 (XY plane) = (2.0 + L/200) m
U1 (Z-axis) = (1.5 + L/50) m [Where L = measuring length in mm. All specifications apply to a thermally stable machine and artifact at 20 C +/- 0.5 C using a 6.6x objective lens.]
Measuring Range: 300 x 300 x 150mm (12 x 12 x 6")
Resolution: 0.1 m (0.000004")
Stage Drive System: DC servo motor drives
Stage Drive Velocity: 254 mm per/sec
Stage Drive Acceleration: 508 mm per/sec2
Stage Error Mapping: Non-linear 2D error corrections in XY plane
Load Capacity: 25kg (55 lbs.)
Optical System: Standard: Fixed, flat field objective lenses
Optical Magnification: Standard: 6.6x (200x on-screen magnification)
Optional: 1.0x-150x (up to 4200x on-screen magnification)
Illumination Standard: Backlight and coaxial surface illumination.
Optical Sensor: Digitally processed instrument quality monochrome CCD camera with 756 x 581 pixel array.
Image Processing: 256, 8-bit, grayscale gradient processing with 5:1 - 50:1 subpixeling (application dependent). Programmable filtering and outlier point removal. Continuous point edge finders, area centroid, histogram, blob (defect), and autofocus tools.
Specifications are subject to verification
