20 kva cammann c-106XA tap disintegrater, cmbl head
20 KVA Cammann C-106XA TAP DISINTEGRATER, CMBL Head
MODEL: C-106XA S/N: 91584 NEW: 1984
KVA RATING:................................ 20 KVA
OVERALL TABLE SIZE:........................ 33" X 54"
TABLE WORK SURFACE:........................ 26" X 47"
MAX. LBS OF WORKPIECE ON TABLE:............ 8000 LBS.
APPROX.MAX.DISTANCE FROM TABLE TO BOTTOM
OF ELECTRODE HOLDING CHUCK:.............. 25-1/4
SPINDLE TRAVEL:............................ 9"
DIAMETER OF COLUMN:........................ 4"
HEIGHT OF VERTICAL COLUMN:................. 23"
HORIZONTAL TRAVEL OF HEAD ON CROSS ARM:.... 30"
VERTICAL TRAVEL OF HAD ON COLUMN:.......... 23"
APPROX. THROAT CLEARANCE:.................. 34-1/2"
ROTATION OF CROSS ARM ON COLUMN:........... 360 DEG.
CUTTING HEAD ON ARM:..... 360 DEG.
APPROX. MACHINE LBS:....................... 2500 LBS.
CASTERS FOR MACHIE PORTABILITY
SINGLE PHASE/460 VOLT, 60 CYCLES ELECTRICS
AS NEW, ALL ORIGINAL CONDITION & APPEARANCE **
