Large thermolyne muffle furnace
LARGE Thermolyne Muffle Furnace
This is a Thermolyne Muffle Furnace model F-A1730. It is 240V, 24 Amp, 1 Phase and is S/N 08510405. It has 69 Cycles. It has the thermocouple for an extended controller, but does not have the controller which does not come with it new, either. We can build one for you, for an extra fee, if you desire. It is guaranteed to be working.
Firebrick and Steel for Demanding Applications
* Up to 1.5 cubic ft. capacity
* Choice of controllers ordered separately
* Heavy-duty firebrick insulation. Hard, abrasion resistant, designed to support heavy loads
* Heavy duty steel case supports the most demanding requirements
* Door is filled with refractory cement for long service life
* Models F1600 and F1700 heating elements embedded in special refractory cement offer long service life, protection from harmful materials and mechanical shock
* Heating elements located on all four sides of chamber for maximum heat transfer and chamber uniformity
* Accessories: Supplied with ceramic hearth try to protect bottom heating element
* No power cord supplied; electrical connection requires fixed wiring
* Controllers sold separately
* For safety, door is counter-weighted to open upwardly; hot side is away from operation
* Heat treating tools and ties
Available Controllers (Sold Separately)
* Output power adjustment can be set from 1% to 100% for furnace operation below 260 C (500 F)
* Controllers can be operated in ambient temperatures of 0 50 C (32 122 F) and field adjusted to change input type, ramp rates and dwell times
* Solid state relay to control power to furnace
* All hardware for mounting, plus conduit and wiring to connect controller to a Barnstead Thermolyne muffle furnace
* Choose from 3 temperature control models:
B1: Digital single set point control with a single ramp to set point and a dwell. A single display shows actual temperature or set point. The furnaces that use this control also utilize a mechanical Over Temperature Protection relay
C1: Digital programmable control with one stored program of 8 segments. The furnaces that use this control also utilize a mechanical Over Temperature Protection relay
D1: Digital programmable control with 4 stored programs, 16 segments per program. The controller also includes RS232 communications. The furnaces that use this control also utilize a mechanical Over Temperature Protection relay
FA1850-1, 3FA1858-1, 3FA1850-1, 3F1856-1 - 302 - 2480 F
FA1630-1, FA1635-1, FA1638-1, FA1738-1, FA1730-1, FA1736-1, FA1748-1, FA1740-1, FA1746-1 - 302 - 1999 F
FA1630-1, FA1635-1, FA1638-1 - 346 cu.in. / 5.7 L
FA1738-1, FA1730-1, FA1736-1 - 1088 cu. in. / 17.7 L
FA1748-1, FA1740-1, FA1746-1 - 1451 cu. in. / 23.7 L
FA1850-1, 3FA1858-1, 3FA1850-1, 3F1856-1 - 1.5 cu. ft. / 41.4 L
FA1630-1, FA1635-1, FA1638-1 - 160 lb / 72.5 kg
FA1738-1, FA1730-1, FA1736-1 - 420 lb / 190.5 kg
FA1748-1, FA1740-1, FA1746-1 - 480 lb / 209.2 kg
FA1850-1, 3FA1858-1, 3FA1850-1, 3F1856-1 - 800 lb / 362.8 kg
3FA1858-1, 3FA1850-1, 3F1856-1 Models require 3 phase power
