Dayton cabinet supply fan 161800
USED FOR COMMERCIAL/INDUSTRIAL APPLICATIONS THAT REQUIRE DELIVERY OF HIGH VOLUMES OF AIR AT LOW STATIC PRESSURES, ASSEMBLED BELT DRIVE, PROPELLER DIAMETER: 36 IN, CFM @ 0.000-IN SP: 13913, @ 0.125-IN SP: 12435, @ 0.250-IN SP: 10121, SONES @ 0.125-IN SP @ 5 FT: 21, FAN RPM: 619, MAXIMUM INLET TEMPERATURE: 104 F, VOLTAGE: 208-230/460, 60 HZ, 3 PHASE, FULL LOAD AMPS: 4.6-4.2/2.1, MOTOR HP: 1-1/2, BEARING TYPE: REGREASEABLE CAST PILLOW BLOCK, MOUNTING POSITION: VERTICAL, PROPELLER MATERIAL: FABRICATED STEEL, INCLUDES 1-1/2 IN WIDE MOUNTING FLANGE, EXHAUST DAMPER BLADE IS TOP PIVOTING GRAVITY RETURN, SUPPLY DAMPER BLADE IS BOTTOM PIVOTING SPRING RETURN, UL AND CUL LISTED, MINOR DAMAGE TO BIRD SCREEN, DIMS: 40-1/4" H X 40-1/4" W X 34" D, WEIGHT: 238 LBS
